Extended abstract

NW Iberia includes a rather complete section

of a Variscan suture, where different terranes

with continental or oceanic affinities appear with

clear structural relationships. Three groups of ter-

ranes, namely Upper, Ophiolitic and Basal units

and a frontal tectonic mélange appear in Galicia,

in Cabo Ortegal, Órdenes and Malpica-Tui com-

plexes. They constitute a huge allochthonous pile

thrust over the Iberian parautochthonous and

autochthonous domains, which represent the

section of the Gondwanan margin that escaped

continental subduction during the Variscan cy-

cle (Schistose Domain of Galicia-Trás-os-Montes

and Central Iberian Zone).

In the Upper Units,

c.

12000 m of terrigenous

sediments (Órdenes Series) intruded by large

massifs of Cambrian (

c.

500 Ma) I-type calc-al-

kaline granitoids (Corredoiras Orthogneiss)

and tholeiitic gabbros (Monte Castelo Gabbro),

are considered to represent a section of a mag-

matic arc built up in the periphery of Gondwa-

na during Neoproterozoic-Cambrian times. Nd

model ages from the Cambrian topmost turbid-

itic series (Ares-Sada greywackes) are relatively

young (720-1215 Ma) and suggest proximity to

some Avalonian terranes. The uppermost part of

this terrane was affected by metamorphism rang-

ing between the greenschist facies and the inter-

mediate pressure granulite facies conditions (IP

Upper Units), dated at 496-484 Ma. The IP Upper

Units can be considered a relic section preserving

the Cambrian tectonothermal activity associated

with peri-Gondwanan arc activity. That activity

was caused by magmatic underplating and fol-

lowed by accretion of arc slices, which developed

counter-clockwise P-T path evolution. However,

the lower part of this terrane shows a completely

different tectonothermal record, as it was affect-

ed by intense high-P and high-T metamorphism

(HP-HT Upper Units; Cedeira and Capelada

units in the Cabo Ortegal Complex, Sobrado

Unit in the Órdenes Complex). This event devel-

oped extensive recrystallization under eclogite

and granulite facies conditions, the peak pres-

sures being in the range of ultra-high-P meta-

morphism (proved minimum pressure at 22 Kb,

with some indicators of higher values). The high/

ultra-high-P metamorphism (

c.

400 Ma) was fol-

12

3. GEOLOGICAL FRAMEWORK

lowed by drastic and fast exhumation coeval with

partial melting (

c.

390 Ma). The development of

extensional detachments (

c.

375 Ma), recumbent

folds and thrusts drove the exhumation of this

high-P complex later on.

True MORB ophiolites derived from typical

oceanic lithosphere are unknown in the Variscan

suture of Galicia. On the contrary, the mafic-ul-

tramafic sequences preserved in NW Iberia were

generated in supra-subduction settings, their

mafic rocks showing island-arc tholeiitic compo-

sition. There exist two critical oceanic to transi-

tional crust-forming events: a Middle-Late Cam-

brian phase (

c.

500 Ma, Lower Ophiolitic Units,

Vila de Cruces and Bazar unit), and a Middle De-

vonian phase (

c.

395 Ma, Upper Ophiolitic Unit,

Careón, Purrido and Moeche units). Both types

of mafic units were accreted beneath the Upper

Units during Variscan convergence, the Upper

Ophiolites first (

c.

391-377 Ma), and then the

Lower Ophiolites (

c.

367 Ma). Due to their buoy-

ant nature, many Devonian ophiolites escaped

from early-Variscan subduction, so they are the

most common ophiolites preserved in the Vari-

scan suture across Europe. The mafic-ultramafic

sequence of the Bazar Unit has been interpreted

as peri-Gondwanan oceanic lithosphere accreted

beneath the magmatic arc system at 480 Ma. This

unit is the only one in NW Iberia showing low-P

granulite facies conditions, which has been linked

to mid-ocean ridge subduction under Gondwana

and the opening of an asthenospheric window.

The Basal Units consist of a thick sequence

of Ediacaran-Early Ordovician terrigenous

metasedimentary rocks intruded by Cambrian

to Ordovician granitoids (calc-alkaline to per-

alkaline) and minor mafic igneous rocks. These

units are considered to outline the most exter-

nal part of the Gondwanan paleomargin during

the Late Devonian. However, detrital zircon age

populations along with (very old) Nd model ages

obtained from well-preserved turbiditic series

(ranging between 1782 and 2223 Ma) indicate a

paleoposition further to the East than the arc-re-

lated section preserved in the Upper Units. The

Basal Units also represent a continental paleo-

subduction zone affecting a wide and continuous

section of the margin at the onset of the Vari-

scan collision (

c.

370 Ma). Subduction polari-

ty was to the W (present-day coordinates) and
